Impacts of CVAD 2003 Support Changes and LTSR 1912 Relevance

A significant number of changes on support stances are being introduced with Citrix Virtual Apps and Desktops 2003 Current Release. These changes will directly impact the supportability of many environments and need to be considered when scoping or performing any form of upgrade/implementation works.

The most impactful change is the new stances on public cloud workloads. Details can be found here. Key takeaways are below:

  • A site running on Citrix Virtual Apps and Desktops 2003 or higher with workloads in public clouds will be an unsupported configuration
  • Customers running Citrix Virtual Apps and Desktops service in Citrix Cloud and customers following the Long-Term Service Release (LTSR) deployment track are not impacted by this announcement. Citrix Virtual Apps and Desktops 1912 LTSR will continue to support public cloud workloads
  • Customers who typically upgrade to the latest Current Release and leverage cloud workloads have two options:
    • Remain on the Citrix Virtual Apps and Desktops 1912 release, which has full support for public cloud providers.  As an LTSR release, 1912 will not receive new feature updates, but has a support lifecycle of 5+ years and is regularly updated with security patches and fixes through Cumulative Updates
    • Migrate to Citrix Virtual Apps and Desktops service. The Citrix Virtual Apps and Desktops service offers full support for public cloud and on-premises workloads and the latest integration enhancements
  • There is no technical enforcement in Citrix Virtual Apps and Desktops 2003; however, a Citrix Virtual Apps and Desktops 2003 site with public cloud workloads will be treated as an unsupported configuration.  A future Current Release will enforce this change
  • To ensure continuity, Citrix recommended that customers with workloads in public clouds do not upgrade to CVAD 2003 and instead remain on CVAD 1912 or move to the Citrix Virtual Apps and Desktops service

When product enforcement is in place, it will focus on VDA workloads and does not impact controllers. A customer may run their Citrix Virtual Apps and Desktops infrastructure in public clouds and connect to on-prem workloads if they choose

A summary of Cloud Platform Support Changes is below:

  • 1912 LTSR will be the last release supported on Public Cloud Providers from a VDA perspective IF you are leveraging a traditional Citrix deployment on-premises or on-cloud
  • You can choose to run Current Release based infrastructure components on-cloud should you so wish, but your VDA workloads must not run on-cloud past the 1912 LTSR release. These workloads must live on-premises
  • If you are using Citrix Cloud, Current Release VDA components will be supported on public Cloud as per current support models

The below tables outline the supported stance for 2003 and 1912 LTSR.

Sources:

SUPPORTED HYPERVISOR/PLATFORM

The following table summarises the support for Hypervisor/Platforms:

Release Version

Supported Platform

2003 Current Release

  • Citrix Hypervisor (formerly XenServer)
  • Microsoft System Center Virtual Machine Manager
  • Nutanix Acropolis
  • VMware vSphere (vCenter + ESXi)

1912 LTSR

  • Amazon Web Services (AWS)
  • Citrix Hypervisor (formerly XenServer)
  • CloudPlatform (deprecated)
  • Microsoft Azure Classic (deprecated)
  • Microsoft Azure Resource Manager
  • Microsoft System Center Virtual Machine Manager
  • Nutanix Acropolis
  • VMware vSphere (vCenter + ESXi)

There are no changes on the support or requirements associated with Active Directory:

Release Version

Supported Platform

2003 Current Release

  • Windows Server 2016
  • Windows Server 2012 R2
  • Windows Server 2012
  • Windows Server 2008 R2

1912 LTSR

  • Windows Server 2016
  • Windows Server 2012 R2
  • Windows Server 2012
  • Windows Server 2008 R2​

DATABASE SUPPORT CVAD 2003

You might need to upgrade your SQL Server version before you can upgrade your Citrix components. Some key takeaways below:

  • Site databases: SQL Server 2008 R2, 2012, and 2014 are no longer supportedfor the site database (This includes the monitor and configuration logging databases.)
  • Local host cache database: SQL Server version 2014 is no longer supportedfor the local host cache database
  • For upgrades, any existing SQL Server Express version is notupgraded
  • Microsoft SQL Server Express LocalDB 2017 with Cumulative Update 16 is installed for use with the Local Host Cache feature. This installation is separate from the default SQL Server Express installation for the site database. (When upgrading a Controller, the existing Microsoft SQL Server Express LocalDB version is notupgraded

Citrix Provisioning 2003 adds support for Microsoft SQL Server 2019

A summary table below outlines database supported stance for 2003 and 1912 LTSR:

Release Version

Supported Database Services

2003 Current Release

  • SQL Server 2019, Express, Standard, and Enterprise Editions – Supported
  • SQL Server 2017, Express, Standard, and Enterprise Editions – Supported (Default: SQL Server Express 2017 with Cumulative Update 16 is installed when installing the Controller)
  • SQL Server 2016 SP2, Express, Standard, and Enterprise Editions

1912 LTSR

  • SQL Server 2017, Express, Standard, and Enterprise Editions
  • For new installations: By default, SQL Server Express 2017 with Cumulative Update 16 is installed when installing the Controller, if an existing supported SQL Server installation is not detected
  • For upgrades, any existing SQL Server Express version is not upgraded
  • SQL Server 2016 SP1 and SP2, Express, Standard, and Enterprise Editions
  • SQL Server 2014 SP1 through SP3, Express, Standard, and Enterprise Editions
  • SQL Server 2012 through SP4, Express, Standard, and Enterprise Editions

OPERATING SYSTEM SUPPORT

Windows Server 2012 R2: Delivery Controllers, Studio, Director, VDAs, or the Universal Print Server are no longer supported for clean install or upgrades

A summary table below outlines database supported stance for 2003 and 1912 LTSR:

Role

Release: 2003 CR

Release: 1912 LTSR

Delivery Controller

  • Windows Server 2016, Standard and Datacenter Editions, and with the Server Core option
  • Windows Server 2019, Standard and Datacenter Editions, and with the Server Core option
  • Windows Server 2019, Standard and Datacenter Editions, and with the Server Core option
  • Windows Server 2016, Standard and Datacenter Editions, and with the Server Core option
  • Windows Server 2012 R2, Standard and Datacenter Editions, and Server Core for Windows Server 2012 R2

Citrix Studio

  • Windows Server 2019, Standard and Datacenter Editions
  • Windows Server 2016, Standard and Datacenter Editions
  • Windows 10 (64-bit only)
  • Windows Server 2019, Standard and Datacenter Editions
  • Windows Server 2016, Standard and Datacenter Editions
  • Windows Server 2012 R2, Standard and Datacenter Editions
  • Windows 10

Citrix Director

  • Windows Server 2019, Standard and Datacenter Editions, and with the Server Core option
  • Windows Server 2016, Standard and Datacenter Editions, and with the Server Core option
  • Windows Server 2019, Standard and Datacenter Editions, and with the Server Core option
  • Windows Server 2016, Standard and Datacenter Editions, and with the Server Core option
  • Windows Server 2012 R2, Standard and Datacenter Editions, and Server Core for Windows Server 2012 R2

Citrix StoreFront

  • Windows Server 2019, Standard and Datacenter Editions, and with the Server Core option
  • Windows Server 2016, Standard and Datacenter Editions, and with the Server Core option
  • Windows Server 2019, Standard and Datacenter Editions, and with the Server Core option
  • Windows Server 2016, Standard and Datacenter Editions, and with the Server Core option
  • Windows Server 2012 R2, Standard and Datacenter Editions, and Server Core for Windows Server 2012 R2

Citrix VDA – Single OS

  • Windows 10 (x64 only), minimum version 1607
  • Windows 10 (x64 only), minimum version 1607

Citrix VDA – Multi Session OS

  • Windows Server 2019, Standard and Datacenter Editions
  • Windows Server 2016, Standard and Datacenter Editions
  • Windows Server 2019, Standard and Datacenter Editions
  • Windows Server 2016, Standard and Datacenter Editions
  • Windows Server 2012 R2, Standard and Datacenter Editions

Provisioning Server

  • Windows Server 2019, Standard and Datacenter Editions
  • Windows Server 2016, Standard and Datacenter Editions
  • Windows Server 2019 Standard and data center editions
  • Windows Server 2016 Standard, and data center editions
  • Windows Server 2012 R2, Standard, Essential, and data center editions
  • Windows Server 2008 R2, and Windows Server 2008 R2 SP1; Standard, Enterprise, and data center editions

Universal Print Server

  • Windows Server 2019
  • Windows Server 2016
  • Windows Server 2019
  • Windows Server 2016
  • Windows Server 2012 R2

WEM Brokers (Not Subject to LTSR)

  • Windows Server 2016 Standard and Datacenter editions
  • Windows Server 2019 Standard and Datacenter editions
  • Windows Server 2012 R2 Standard and Datacenter editions
  • Windows Server 2016 Standard and Datacenter editions
  • Windows Server 2019 Standard and Datacenter editions

MISC

  • Donet Framework 4.8 will now be the minimum required version for Citrix components with a dotnet requirement – time to update task sequences and/or reference images with the dotnet components prior to installing Citrix components
  • PVD was deprecated a long time ago, it will now be removed from the GUI entirely, interestingly Personal vDisk functionality is still supported when using earlier VDAs with Citrix Virtual Apps and Desktops 7 2003 Delivery Controllers
  • If you have been running command line installers, the /baseimage command line switch will break your deployments
  • Installing the Microsoft Visual C++ 2017 Runtime on a machine that has the Microsoft Visual C++ 2015 Runtime installed can result in automatic removal of the Visual C++ 2015 Runtime. This is as designed.
  • Citrix License Server 11.16 and later is supported
  • AppDNA 7.8 and AppDNA 7.9 are not supported with this release

DEPRECATIONS AND FEATURE REMOVAL

  • Self Service Password Reset (SSPR)
  • Azure and AWS public cloud (including VMware Cloud on AWS) connections (removed also)
  • Citrix Indirect Display Driver (IDD) graphics adapter support on Windows 10 version 1709 and earlier (removed also)
  • Hardware encoding with Nvidia GPUs (NVENC) using GRID 9 or earlier display drivers (removed also)
  • Support for Microsoft .NET Framework versions prior to version 4.8 for VDAs and core server components. Includes Delivery Controller, Studio, Director, and StoreFront.
  • VDAs on Windows Server 2012 R2
  • AppDNA application migration component of Citrix Virtual Apps and Desktops Premium edition
  • Installing Studio on 32-bit (x86) machines
  • Core server components on Windows Server 2012 R2 (including Service Packs). Includes: Delivery Controller, Studio and Director
  • Support for Site Configuration, Configuration Logging, and Monitoring databases on Microsoft SQL Server versions 2008 R2, 2012, and 2014 (including all Service Packs and editions)

FINAL SUMMARY VDA SUPPORT BREAKDOWN

The below table summarises VDA support with a focus on changes. Check product documentation for other VDA support scenarios relating to Current Release etc:

Server OS

Citrix On-Premises

Citrix On Premises or On Cloud with Public Cloud VDA workloads

Citrix Cloud (Any platform)

Windows Server 2008 R2

7.15 LTSR CU5 VDA

7.15 LTSR CU5 VDA

7.15 LTSR CU5 VDA

Windows Server 2012 R2

1912 LTSR VDA

1912 LTSR VDA

1912 LTSR VDA

Windows Server 2016

1912 LTSR VDA

Current Release VDA

1912 LTSR VDA

1912 LTSR VDA

Current Release VDA

Windows Server 2019

1912 LTSR VDA

Current Release VDA

912 LTSR VDA

1912 LTSR VDA

Current Release VDA

Windows 10

1912 LTSR VDA

Current Release VDA

1912 LTSR VDA

1912 LTSR VDA

Current Release VDA

Windows 10 Multi Session

Not Applicable

Not Applicable

1912 LTSR VDA

Current Release VDA
